Selective wave soldering machine
Selective wave soldering machine
Overview
Unique spray process, stable welding selection effect, small batch production of preferred welding equipment, low cost, high flexibility
Product features
Special designed point flux injection;
High precision, high stability selection spot welding (single and double head optional)
Nozzle automatic cleaning , automatic calibration of jet height, automatic addition of solder and miniaturization design;
Configure the AIVS manufacturing platform;
Realize the online repair function by connecting AOI
|
Type |
Specification |
Selective wave soldering machine |
|
Technical parameter |
Machine size |
L800*W1400*H1400mm |
|
Mechanical pump groove |
Standard：single cylinder×1个 |
|
|
Spray nozzle diameter |
φ3-12mm |
|
|
Wave height |
Max:5mm |
|
|
PCB gap |
Min:3mm |
|
|
Tin furnace capacity |
8KG/ Solder furnace |
|
|
Soldering temperature |
Max : 320℃ |
|
|
Temperature control accuracy |
±1℃ |
|
|
Heating time |
40Min/（300℃) |
|
|
Tin furnace power |
1KW/ Solder furnace |
|
|
Moving speed |
X/Y：2 – 400 mm/s |
|
|
Z：2 – 50 mm/s |
||
|
Wave accuracy |
±0.5mm |
|
|
Repeated accuracy |
±0.05mm |
|
|
Spray width |
2-8 mm |
|
|
Size of spray nozzle |
130um |
|
|
Spray way |
Linear |
|
|
Pressure |
0.5Mpa |
|
|
Nitrogen consumption |
1.5m |
|
|
Particles cleanliness |
≥99.99% |
|
|
Nitrogen preheating temperature |
MAX:350℃ |
|
|
Temperature control accuracy |
±1℃ |
|
|
Process visualization |
CCD visible |
|
|
Data import |
Measure Gerber、Images imported online |
|
|
Power |
3P5W,380VAC |
|
|
Frequency |
50/60Hz |
|
|
Consumption |
4.5KW |
|
|
Air supply |
0.5Mpa |
|
|
Automatic solder adding device |
Option |
|
|
Nozzle automatic cleaning device |
Option |
|
|
Spray height correction |
Option |
|
|
AIVS Intelligent manufacturing platform |
Option |
/H
