MWD-800 Microwave Digestion System for Sample Preparation
MWD-800 microwave digestion system is engineered for precise, safe, and efficient sample preparation in trace metal and complex matrix analysis.
MWD-800 microwave digestion system is engineered for precise, safe, and efficient sample preparation in trace metal and complex matrix analysis. It integrates high-capacity batch processing, real-time contactless monitoring, and multi-layer safety protection to ensure consistent analytical performance and high reproducibility in laboratory workflows.
Product Advantages of MWD-800 Microwave Digestion System
-
High-capacity batch digestion
Up to 40 vessels allow simultaneous processing, making the system suitable for high-throughput laboratory environments and routine analytical operations. -
Advanced digestion vessel design
The specially designed vessels feature an auto-vent and self-resealing mechanism. When sudden over-pressure occurs, the system automatically releases pressure and immediately reseals, reducing sample loss and preventing vessel damage. -
Contactless temperature and pressure monitoring system
Each vessel is equipped with an imported IR sensor that measures real-time solution temperature rather than vessel wall temperature. A non-contact pressure sensor monitors each vessel individually, ensuring accurate condition tracking while preventing cross-contamination. Real-time data is displayed throughout the entire digestion process. -
Large method storage capacity
The system supports up to 255 programmable digestion methods. Each method can include up to 10 steps with adjustable parameters such as temperature, pressure, time, and microwave power, enabling standardized and flexible laboratory workflows. -
Multi-layer safety protection system
A combination of a double-lock safety door, real-time monitoring, automatic over-pressure and over-temperature correction, and abnormal sound detection ensures stable and secure operation under high-energy digestion conditions.
Technical Specification of MWD-800 Microwave Digestion System
General Information
| Item | Specification |
|---|---|
| Model | MWD-800 |
| Vessel Quantity | 40 |
| Vessel Volume | 50 mL |
| Display | 7-inch color touch screen |
| Rotation System | 360° continuous rotation (one direction) |
Temperature Monitoring System
| Item | Specification |
|---|---|
| Measurement Method | Contactless IR sensor |
| Control Mode | Individual vessel temperature control |
| Temperature Range | 50–400°C |
| Maximum Working Temperature | 250°C |
| Accuracy | ±0.1°C |
Pressure Monitoring System
| Item | Specification |
|---|---|
| Measurement Method | Contactless pressure sensor |
| Control Mode | Individual vessel pressure control |
| Pressure Range | 0–15 MPa |
| Maximum Working Pressure | 6 MPa |
| Accuracy | ±0.01 MPa |
Materials and Structure
| Item | Specification |
|---|---|
| Sample Vessel Material | Imported TFM |
| Protection Vessel Material | PEEK + Glass Fiber |
| Microwave Cavity | 316L stainless steel with corrosion-resistant coating |
Microwave System
| Item | Specification |
|---|---|
| Microwave Power | 0–3000 W (adjustable) |
| Microwave Leakage | < 5 mW/cm² |
Auxiliary Systems
| Item | Specification |
|---|---|
| Air Exhaust System | High-power corrosion-resistant blower |
| Power Supply | AC 220V ±10%, 10A, 50/60Hz |
